Specifications |
TECHNICAL SPECIFICATION
ENGINE
Engine Type: 4- Stroke, 1- Cylinder, Oil-Cooled
Valve System: SOHC, 4 Valve
Displacement: 249 cm3
Bore X Stroke: 76.0 mm x 54.9 mm
Engine Output: 26.5ps@9000rpm
Torque: 22.6 Nm @7500rpm
Fuel System: Fuel Injection
Starter System: Electric
Transmission Type: 6 Speed, MT
DIMENSIONS AND WEIGHT BRAKE
Wheels: Cast Front
Overall Length: 2010 mm Rear
Overall Width: 740 mm
Overall Height: 1035 mm
Wheel Base: 1345 mm
Ground Clearance: 165 mm
Seat Height: 800 mm
Kerb Mass: 161 kg
Fuel Tank: 12 L
SUSPENSION:
Front: Telescopic, Coil Spring, Oil Damped
Rear: Swing Arm Type, Mono Suspension
Tyre Size
Front: 110/70R - 17 M/C - Radial Tubeless
Rear: 150/60R - 17 M/C - Radial Tub less
Electrical
Battery Maintenance - free, 12V 6Ah
Head Light: LED
Tail Light: LED
|
