Specifications |
ENGINE
Displacement : 125 cc
Max Power : 6.0kW(8.2PS)/6500r/min
Maximum Torque : 10.3 N.m(1.1kgf.m)/5000 r/min (With Assist Function Working)
Bore : 52.4 mm
Stroke : 4 Stroke
Valves Per Cylinder : 2-valve
Compression Ratio : 10.2:1
Fuel Delivery System : Fuel injection
Ignition : TCI (Transistor Controlled Ignition)
Cooling System : Air Cooled
Transmission Type : V-belt automatic
BRAKES, WHEELS AND SUSPENSION
Front Brake Type : Disk / Drum
Rear Brake Type : Drum
Front Tyre Size : 90/90-12 Tubeless
Rear Tyre Size : 110/90-10 Tubeless
Front Suspension : Telescopic fork
Rear Suspension : Unit Swing
DIMENSIONS AND CHASSIS
Kerb Weight : 99kg
Overall Length : 1,880mm
Overall Width : 750mm
Overall Height : 1,190mm
Wheelbase : 1,280mm
Ground Clearance : 145mm
Seat Height : 785mm
OTHER INFORMATION
Fuel Tank Capacity: 5.2L
Battery: Maintenance free - 12V,5.0 Ah
Headlight Type: LED (Class C)
Brake/Tail Light: 12V,21/5W x 1
|
