Specifications |
ENGINE
Engine Type : Single Cylinder, Liquid Cooled, DOHC, FI Engine
Engine Displacement : 199.5 cc
Bore x Stroke : 72 mm X 49 mm
Power (PS) : 25 PS @ 10000 rpm
Power (kW) : 18.4 kW at 10000 rpm
MAX Torque :19.2 Nm at 8000 rpm
Fuel Injection : Bosch Electronic Fuel Injection (EFI)
Lubrication : Forced, Wet sump
Cooling SYSTEM : Liquid cooling. Curved radiator with fans for better heat management
Compression Ratio : 13.3:1
SUSPENSION
Front Suspension: WP APEX USD forks, 43 mm diameter
Rear Suspension : WP APEX Monoshock, 10 step adjustable
Frame : Split-Trellis frame (Tubular)
Sub Frame : Newly engineered bolt-on subframe
BRAKES
Front Brake TYPE: 320 mm Disc with Radially mounted calliper
Rear Brake TYPE: 230 mm Disc with Floating calliper
DIMENSION AND CAPACITY
Fuel Tank Capacity: 13.7 L
Ground Clearance : 156 mm
Saddle Height : 835 mm
Kerb Weight : 160 kg
FEATURES
Rider Aids : Supermoto ABS
ELECTRONICS
Starter / Battery : 12 V, 8 AH MF battery
|
