Specifications |
ENGINE AND PERFORMANCE
TYPE: SINGLE CYLINDER, 4 STROKE, AIR COOLED, SOHC,
FUEL INJECTION: 78MM X 86MM
DISPLACEMENT: 411 CC
COMPRESSION RATIO: 9.5:1
MAXIMUM POWER: 24.3BHP(17.88KW)@6500RPM
MAXIMUM TORQUE: 32NM@4250±250RPM
IDLE RPM: 1300±100RPM
STARTING SYSTEM: ELECTRIC START
AIR FILTER ELEMENT: PAPER ELEMENT
LUBRICATION: WET SUMP
ENGINE OIL GRADE: SEMI SYNTHETIC SAE 15W 50 API SL
GRADE JASO MA 2
IGNITION SYSTEM: DIGITAL ELECTRONIC IGNITION
CLUTCH: WET MULTI PLATES
GEARBOX: 5 SPEED, CONSTANT MESH
FUEL SUPPLY: ELECTRONIC FUEL INJECTION
CHASSIS AND SUSPENSION
TYPE: HALF-DUPLEX SPLIT CRADLE FRAME
FRONT SUSPENSION: TELESCOPIC, 41 MM FORKS 190MM TRAVEL
REAR SUSPENSION: MONOSHOCK WITH LINKAGE,V180MM WHEEL TRAVEL
DIMENSION
WHEELBASE: 1455 MM
GROUND CLEARANCE: 200 MM
LENGTH: 2160 MM
WIDTH: 840 MM
HEIGHT 1165 MM
SEAT HEIGHT: 795 MM
KERB WEIGHT (WITHOUT FUEL): 185 KG
FUEL CAPACITY: 15 LITRES (APPROX)
BRAKES
TYRES FR.: 100/90 -19 "
TYRES RR.: 120/90 - 17"
BRAKES FRONT:300MM DISC, 2-PISTON FLOATING CALIPER
BRAKES REAR: 240MM DISC, SINGLE PISTON FLOATING CALIPER
ABS: DUAL CHANNEL ABS
|
