Specifications |
VARIANTS AND PRICES
Xtreme 125R FI ABS: Rs 311,900
Xtreme 125R FI CBS : Rs 289,900
ENGINE AND PERFORMANCE
Acceleration 0-60kmph (sec): 5.9 Sec
Fuel Consumption:66 Kmpl (WMTC- BS VI)
Engine Type: Air Cooled 4 Stroke
Bore & Stroke: 52.4mm X 57.8mm
Displacement (Cm3): 124.7
Max Power (hp/rpm): 11.4BHP @ 8250 RPM
Max Torque (Nm/rpm): 10.5 Nm @6500 RPM
Fuel System: Fuel Injection
DIMENSIONS AND WEIGHT
Overall Length (mm): 2009
Overall Width (mm): 793
Overall Height (mm): 1051
Wheelbase (mm): 1319
Seat Height (mm): 794
Ground Clearance (mm): 180
Trail (mm): 89.2
Fuel Tank Capacity (L): 10 L
Curb Mas (kg) (Self Disc Cast): 136
TRANSMISSION AND CHASSIS
Caster (°): 24.1°
Steering Angle (°): 43°
Frame Type: Diamond
Swing Arm: Tubular - Fabricated
Transmission Type: Constant Mesh , 5 Speed
Clutch Type: Wet Multi Plate
SUSPENSION
Front Suspension Type: Dia. 37 Conventional Fork
Rear Suspension Type: Hydraulic Shock Absorbers
BRAKES
Front Brake Type: Disc Type (CBS) - Dia 240mm, Disc Type (ABS)-Dia 276mm
Rear Brake Type (With CBS): Drum Type- Dia 130
WHEELS AND TYRES
Wheel Type: Alloy
Front Tyre Size: 90/90 - 17 TL
Rear Tyre Size: 120/80 - 17 TL
ELCTRICALS
Battery (V-Ah): MF 12V, 4 AH (ETZ 5)
Starting System: Self (With i3s) & Kick
ACG Capacity (W/rpm): 160 W / 5000 rpm
|
