Specifications |
ENGINE
Type : 4 stroke, Air-Oil Cooled, 4 Valve
Displacement : 163.2 cc
Max Power : 16.9 Ps @ 8500rpm
Max Torque : 14.6 Nm @ 6500rpm
Bore x Stroke : 66.5 mm x 47.0 mm
Compression Ratio :10.1:1
Starting : Self Start
DIMENSIONS AND WEIGHT
Kerb weight : 145 Kg
L X W X H : 2029 mm X 793 mm X 1052 mm
Ground Clearance : 165 mm
Wheelbase : 1333 mm
Seat Height : 795 mm
Fuel Tank Capacity : 12 Litres
TRANSMISSION AND CHASSIS
Frame : Tubular Underbone Diamond Type
Clutch : Multiplate Wet
Transmission : 5 Speed Constant Mesh
SUSPENSION
Front :KYB USD Forks, 37mm Dia
Rear :7 Step Adjustable Monoshock
BRAKES
Front Brake : Disc 276mm Petal
Rear Brake : Disc 220mm Petal
ABS : Single Channel
WHEELS AND TYRES
Front : 100/80-17 (Tubeless)
Rear : 130/70 R17 (Tubeless)
ELECTRICAL
Battery : 12 V-6AH (VRLA)
Lamps : LED Headlight with Position Lamp, LED Tail Lamp and LED Winkers
Speedometer : Inverted LCD Console
|
