Specifications |
Model Information :
Model Name : Morbidelli T250X
Model Year : 2026
Category : Trail
Engine :
Displacement (c.c) : 249.4
Type : 1-cylinder/4-stroke/4-valve
Bore x Stroke : 71×63
Power (hp/rpm) : 22.38/7500
Max Torque : 22.3N·m/6000 r/min
Compression ratio : 9.6:1
Fuel system : EFI
Valve train : SOHC
Ignition system : TCI
Starter : Electric
Lubrication system : Pressure splash lubrication
Cooling System : Air-Cooled
Transmission :
Gear shifting type : 6-speed
Transmission type : Chain
Clutch type : Wet multi-plate
Chassis :
Frame : Double-cradle
Front Wheel : Spokes
Front Suspension : 41mm upside-down telescopic forks
Front Suspension travel (mm) : 177
Front Tyre : 90/90-19
Rear Wheel : Spokes
Rear Suspension : Mono-shock-absorber, preload adjustable
Rear Suspension travel (mm) : 56
Rear Tyre : 110/90-17
Front Brake : Disc, 2-piston caliper
Front brake diameter (mm) : 265
Rear Brake : Disc, 2-piston caliper
Rear Brakes diameter (mm) : 220
Dimensions and Weights :
Curb Weight (kg? : 154
Seat height (mm) : 820
Wheelbase : 1340
Overall length (mm) : 2050
Overall width (mm) : 975
Overall height (mm) : 1330
Ground clearance (mm) : 220
Fuel Capacity (L) : 11.7
Top speed (km/h) : 120
Max Loadage (kg) : 180
Battery : 12V, 6.5Ah
Multimedia & comfort features :
Dashboard type : Vertical LCD, Rally Inspired
Gear indicator : Included
USB charging port : Type-A
Handle switch with illumination : Included
Lighting configuration :
Headlight : X-Stack LEDS, Dual LED projector lenses for optimal visibility
Taillight : LED
Turn signal : LED
Hazard light : Included
Automatic lighting system : Included
|
